Tag: Plumbing Products

One-Handed Drain Installation

The Razorback Drain Wrench features a unique design that allows for one-handed installation of drains from the top or bottom. This versatile wrench fits popular basket strainers and shower drains.

• Eliminates the need for all other “Box End” wrenches
• Fits most common styles of brass and plastic shower and sink drains
• “T” handle rotates 180° for easy access and maximum leverage
• Made of extremely durable, high impact polycarbonate polyester
• Ideal for working in tight areas
• Ideal for retrofits and new installations

The new T&S Brass LakeCrest Metering Faucet combines T&S’ time-tested classic metering cartridge with an improved design and upgraded look, all in an American-made package. The single-temperature metering faucet pairs with their universal forged deck plates, and features a vandal-resistant nozzle.

Specifications

• 1/2” NPSM male inlet
• Inlet: 3/8 Compression
• 24” flexible stainless steel supply hose w/ 3/8” O.D. compression connection
• Adjustable metering cycle, 10 to 30 seconds
• Material: Polished chrome plated brass body & chrome plated push button
• Metering cartridge
• Push button cap w/ screw & index
• Single hole, single temperature deck mount faucet w/ polished chrome plated brass body
• VR 0.5 GPM hidden non-aerated spray device
• Pressure Max: Pressure Max: 125 psi (8.62 bar)
• Pressure Min: Pressure Min: 20 psi (1.38 bar)
• Temperature Max: Temperature Max: 140 F (60°)
• Temperature Min: Temperature Min: 40 F (4.44°)

Cut pipe fast and efficiently with the RIDGID Pipe Saw. From the fab shop to the field, this tool delivers quality cuts on 1 inch to 12 inches. The tool secures onto the pipe in seconds, making setup and operation a breeze. Fast and easy to use, the Pipe Saw lets you focus on the tasks that require more time and effort.

Ridgid Pipe Saw Features

• Interchangeable cutting head works with 2 clamp sizes (1” – 6” and 6” – 12”) to cut up to 12” pipe with a ½” wall thickness
• Powerful motor and optimal blades cut through carbon steel, stainless steel, plastic, cast iron and ductile iron with ease (10” Schedule 40 Pipe in just over a minute).
• Quick adjustment features and integrated alignment pad allow for mounting in seconds
• Pivot plunge design and speed monitoring with LED interface for optimal feed control
• Rigid 3-point roller system with one directional bearings secure to the pipe ensuring quality cuts
• Conveniently placed handlebars allow for easy, comfortable and controlled rotation
• Integrated handle and dedicated cord wraps

Specifications:

Nominal Cutting Capacity – Small Clamp: 1″ to 6″ (50mm to 150mm). Large Clamp: 6″ to 12″ (150mm to 300mm).

Maximum Wall Capacity – ½” (12mm), For Plastic Only 0.70” (18mm)

Pipe Material – Steel, Stainless Steel, Plastic, Cast Iron

Cut Quality – (Max. Offset) 0,050″ (1.27mm)

Weight – Small Clamp: 49 lbs. (22.2 kg) Large Clamp: 52 lbs. (23.6 kg)

Available Configurations

Catalog No.	Model No.	Description
66388	PCS500 & PC106	Cutting head and 1″-6″ Small Clamp
66393	PCS500 & PC612	Cutting head and 6″-12″ Large Clamp
66398	PCS500, PC106 & PC612	Cutting head, Small Clamps, and Large Clamp
66378	PC106	1″-6″ Clamp only
66383	PC612	6″-12″ Clamp only
67883	PCS500	Pipe Saw Cutting Head only

Accessories

Cat No.	Description
66413	Saw Blade for Steel and Stainless Steel (Cermet-Tipped)
69053	Saw Blade for Plastic Pipe (Carbide-Tipped)
69988	Saw Blade for Cast Iron (Diamond Abrasive)

Sloan’s CX concealed flushometer is their most innovative flush valve design in over 50 years. Available in both sensor and manual options, the Sloan CX Concealed Flushometer range can be installed in either battery-powered or hardwired configurations. Sloan CS concealed flushometers are available in five finish options to suit any style restroom.

Sloan CX Concealed Flushometer Features

• Manual or sensor
• Battery powered or hardwired
• 5 finish options
• Water closets 1.1, 1.28, and 1.6 gpf
• Urinals 0.125, 0.25, and 0.5 gpf

Innovative Design

The Sloan CX concealed flushometer features the industry’s smallest front access wall panel, nearly 70% smaller than the industry standard. It is vandal resistant, ensuring impressive product longevity that won’t tarnish over time. The CX’s small size and concealed valve allows for it to be an integral part of any restroom without interrupting the integrity of the design or architecture.

Exceptional Finish

Sloan works closely with architects and designers around the world to ensure that their efficient, water-saving products are also beautiful. With a choice of Polished Chrome or 4 attractive PVD finishes, including their newest color, Graphite, the CX allows you to make the statement of your choice that elevates your restrooms.

Sloan CX Concealed Sensor Flushometer Finishes

Sloan CX Concealed Manual Flushometer Finishes

The Sloan CX Sensor is Easy to Install…

Not only is CX pleasing to the eye, it doesn’t require a rear access plumbing chase, meaning up to 60% more usable space in every restroom. The CX Flushometer will not only surpass all design and ease of use expectations, it will also vastly contribute to any property’s annual water savings with high efficiency water conservation technology.

The CX streamlines the installation process. Instead of bringing the valve to the plumbing, the CX features an integrated control stop and adjustable flush connection, with an all-vertical, in-line, rough-in that allows the installer to bring the plumbing to the valve.

And Easy to Maintain

Once installed, all the servicing of repair parts can be done single-handedly in front of the wall, through the wall plate using half the labor. No longer do facility managers need to navigate, narrow, congested plumbing chases for routine repairs.

T&S Brass was the first to develop a pre-rinse faucet system, and they’ve revolutionized the design process by offering customizable systems that suit any set of needs, whether they be low-profile, ergonomic, or high-powered performance.

Their low-flow solutions can save thousands in utility bills and support a sustainable business practice.

---

Add-On Options for Pre-Rinse Faucets

Choose your spray valve (for all units except DuraPull) and customize your unit with add-ons and accessories to increase productivity, reduce waste, and extend the life of your finished design.

Add-on Swivel
Cartridges
Vacuum Breakers
Wall Brackets
Add-on Faucets
Brush Attachments for Spray Valves
Tees to supply water to accessory applications

---

T&S Brass UltraRinse Faucet Units

The ULTRARINSE Difference

• Angled fan spray tips maximize surface area contact, clean and rinse more quickly
• Hands-free operation
• Rinses away particulates and bacteria that regular faucets’ spray patterns can leave behind
• Great for rinsing produce and thawing foods
• Retrofits T&S manual faucets and Pre-Rinse Units (requires swivel outlet body)
• Available in two lengths – 10” length for use with 12” nozzles and 16” length for use with 18” nozzles
• Promotes food safety
• Reduces food damage and waste
• Patented – US Patent # 10,563,384
• Two positions – Spray and Fill. Spray activates the spray fan tips, fill activates the nozzle.

Bathroom partitions are hard to source. Let us do the dirty work!

• Free site measurement for new bathroom partitions
• Fast response time
• Many materials, colors & styles to choose from
• Washroom accessories also available
• No job too large or small
• Personal service
• Ask about plumbing supplies, tools, pipe, valves, fittings, and more!

We work directly with the manufacturer to ensure you get the right product and the right fit – the first time!

Schedule your no-charge site measurement today!

LeakBreaker ® is a water heater leak protection device that protects against flood damage
from the containment failure of a water heater. It consists of a control unit, a valve with
actuator and a sensor. This re-settable, testable protection device can be installed on any
style water heater to shut off the incoming water supply, preventing additional water flow to a
damaged water heater. The two-color LED light and audible alarm lets you know the status of
LeakBreaker ® at all times.

BioArmor® is a new point-of-use secondary water treatment system from Chicago Faucet, designed to treat pathogens using ultraviolet (UV) light emitting diodes.

The compact size allows it to fit under any sink. Plug-and play design for fast, easy installation. Works with any faucet, providing secondary water treatment at a hand washing sink*.

Easily installed between the incoming water lines and the faucet, BioArmor attacks pathogens using UV-C light to penetrate cells and render them microbiologically inactive. When water flow is detected, it delivers instant full-intensity power – without heat transfer – to disinfect the water. For use with any faucet*, BioArmor is designed for long term, low maintenance performance.

Installs between the stop valves and the faucet with standard 3/8˝ compression inlets and outlets. Two independent chambers treat hot and cold at the same time up to 1.5 GPM for convenience and efficiency.

Always know your BioArmor UV-C Disinfection System is operational. Easy to see indicator lights and error alarm deliver ongoing, consistent monitoring.

Simply connect to your BAS to remotely monitor errors and collect data on hot and cold water activations to help calculate UV lifespan and monitor faucet usage.

The system was tested by third-party BCS Laboratories and showed an average 4 log reduction of legionella.

*110VAC to 12DC transformer required.
**The system is not intended to treat water used for medical devices.

---

The 8453 Series Combination Eyewash and Touchless Faucet

Chicago Faucets has combined an independently operated eyewash with a durable, cast brass touchless spout. This space-saving design allows you the extra safety of a fully functional eyewash and a versatile touchless gooseneck faucet without taking up any additional counter space. The eyewash features a large, intuitive push handle for activation with a completely separate supply line for tepid water.

Features include:

• Separate Water Supply: For Eyewash Independent supply line for eyewash allows connection to an ASSE 1071 thermostatic mixing valve to meet code and provide user safety.
• Large Push-Handle: For Easy Activation Intuitive stay-open push handle design for easy-to-locate operation during any eye emergency.
• Durable Construction: Heavy-duty, cast brass faucet body and spout with vandal resistant outlet designed to withstand abuse and tampering.
• A secure compact Control Box mounts below the deck and conceals the power, solenoid, mixing valve, and supply.
• Added Safety: Available with integral ASSE 1070 compliant thermostatic protection to help prevent scalding.
• Optional Commander™ handheld programming unit maintains and monitors your faucets with five running modes, hygiene flush, and usage tracking.

Hands-free, sensor-operated, stand-alone, mobile handwashing station.

Enable more convenient handwashing options for your facility with the new Sloan® Mobile Handwashing Station. The latest touch-free innovation can be placed anywhere in the building, bringing hand hygiene beyond the restroom.

This customizable hygiene station on wheels pairs attractive design with the durability you expect from Sloan. It’s a simple solution that helps your facility enhance health, wellness, and hygiene.

Where hygiene is essential.

Our Mobile Handwashing Station comes with multiple options to fit both indoor and outdoor applications. Perfect for any location where hygiene is essential. Use near entrances or exits, food courts, cafeterias, concourses, concessions, escalators, hallways, and much more.

All stations include AC or DC powered unit and 16 gallon greywater tank. Hot water heater and holder for two 5 gallon.

Features include:

• AC or DC powered unit or battery powered options
• The ADA-compliant station offers accessibility to everyone with an expansive enclosure that allows for greater access underneath and more counter space on top
• 16 gallon greywater tank
• Hot water heater and holder for two 5 gallon water jugs (jugs included) available on select models
• Sloan® SF-2250 or BASYS® EFX-150 sensor-operated faucet on select models
• Corian® sink deck with vitreous china undermount bowl or stainless steel deck with stainless steel drop-in sink
• Touchless enMotion® Paper Towel Dispenser
• Purell® CS-8 Wall-mounted Foam Soap Dispenser
• Handle and trash bag holder
• Lockable caster wheels

---

Battery-Powered Models

These stations are powered by a rechargeable battery and allow for freshwater and greywater storage for stand-alone use with no plugin or plumbing required. Water and drain lines for connected use are also included.

---

---

---

Water line connected handwashing stations

The stations below require connection to a standard 3/4″ water line and drain line for greywater.

---

---
